Goldenwest Huntington Beach Concrete rebuilds walks that rock at the joints, on a rock base that drains above the water this lowland holds beneath it. Every estimate is measured and written on site.
5.0 Stars Rated by our customers · Google, Facebook and the BBB
How a walk is rebuilt here
A sidewalk here fails at its joints before it fails anywhere else, and it fails by rocking. A panel 4 feet wide and 4 inches thick has no weight to hold itself still, so once the base under it is wet and soft every footstep tips it a fraction, and each tip pumps a little water and fine sand out through the joint. The panel settles at one end, its neighbor stays put, and the step between them is the trip edge the City marks in paint. Nothing lifted it. The ground let go underneath.
Goldenwest Huntington Beach Concrete has replaced sidewalk panels across Huntington Beach since 2017, and Scott Ferreira walks every frontage himself before a saw is started. Most of the walks here were poured in one go with the tracts between 1960 and 1975, many of them tight against the curb with no planting strip, so a street reaches the end of its walk all at once, and the panels that go first are the ones over the lowest, wettest ground.
A panel is replaced from score mark to score mark, on clean crushed rock that drains, poured at 4 inches, or 6 where a driveway crosses it, to the width and scoring of the walk either side. The walk is right-of-way, so the work goes in on an encroachment permit from Public Works and the inspector sees the forms. It is done under a CSLB C-8 license with liability insurance on every job, and carries a written workmanship guarantee against defects in how it was built.
Grind or rebuild
Step on one end of a panel and the other end comes up a hair. That is the base gone soft beneath it, and it is the first sign, before any edge shows. A rocking panel is pumping water and sand out through its joints every time someone walks by, and the step at the joint grows.
A dark line along a joint that stays damp after the street has dried is water and fines being squeezed up from below. On the lowland side of town the base is sitting close to the water table, and a stain like this means the panel is already working on it. The joint opens next.
A lip where one panel has dropped below its neighbor is the trip edge, and a quarter inch is the limit the federal accessibility standard sets. A root lifts a panel in the middle. Water drops one at the end, which is what most steps on a walk here are. Grinding buys a year or two.
Cracks in the panels a driveway runs over mean a walk poured for feet has been carrying a car since 1970. A 4-inch panel on a wet base breaks under a wheel, and once it is in pieces every piece rocks on its own. Those panels are urgent, because they fail under a delivery truck.
In every walk
Eight things are in every walk at no separate line, and most of them are below the surface you step on. A panel here has to sit still on ground that stays wet, and it has to match the walk either side of it so nobody can tell where the new one starts.
The failed panel is sawn out on its existing score lines, so the new one lands on the same grid as the rest of the walk instead of adding a joint.
The soft, fine material under it is dug out until the plate compactor stops sinking, however far down that turns out to be on the lowland side.
Clean crushed rock goes in where the fines were, compacted. Water passes through it instead of standing in it, so nothing is left to pump out.
The new panel is formed to the width, height and cross fall of the walk either side, so a wheelchair rolls over the seam without noticing it.
A panel a car crosses is poured 6 inches on mesh and thickened at the approach, and the depth is written on the estimate against each panel.
Steel dowels are drilled into the panels either side so the new one cannot drop below its neighbors, which is how a step at the joint comes back.
The score marks are tooled at the same spacing as the old walk and the edges rounded, so the panel reads as part of the street a month later.
The inspector sees the forms and base before the pour, the barricades come down when the walk can be used, and the guarantee is handed over.
What can be done
Four things that can be done to a walk that has started to rock, set against how long each holds on a base that stays wet. The one that fixes the cause is the last row, and the first three are what a walk usually gets before that.
| Option | Fixes | Holds for | Trip edge | Suits |
|---|---|---|---|---|
| Grinding the lip | The edge only, the panel still rocks | A year or two on wet ground | Gone today, back as the panel drops | A dry-side panel that dropped once |
| Mudjacking the panel | The level, by pumping slurry under it | Until the slurry pumps out too | Closed while the base stays put | A sound panel over fill, not water |
| New panel, old base | The concrete, not the ground | Until the fines pump out again | Closed, then reopens at the joint | The mesa and the dune streets |
| New panel, drained base | The cause, water standing under it | The 30 years a walk is good for | Closed and doweled so it stays | Any lowland frontage, any drive |
By cost, grinding is least, mudjacking next, a panel on its old base after that and a panel on a drained base most; by cost over the years the order flips.
Water and the tract walk
Nothing under this city swells, so the usual reason a walk lifts does not apply. What a walk here has instead is water a few feet below it, and a 1965 base never meant to hold that water off.
The city sits at the mouth of the Santa Ana River, and below the mesa that carries downtown the ground is flat, low and wet. Around Huntington Harbor, along the Bolsa Chica and across the tracts south of Adams Avenue the water table is close enough that a base of sandy fill holds water for weeks after a January storm. A panel on that base is on a sponge. Every step squeezes it, the fines go out through the joint, and by spring the panel has dropped at one end. The mesa streets drain.
The walks themselves were poured at the tract era's pace, between 1960 and 1975, tight to the curb and to the depth of the day, 4 inches with no base under many of them. So a whole street ages together, the driveway approaches go first because they were never poured for cars, and the City paints the lips it finds. Rebuilding one panel at a time on a base that drains is what we do, and where a whole frontage has gone we redo the driveway approach with it on the same permit.
From call to barricades down
Five stages, the same crew at each, and the walk is closed to your neighbors for the shortest stretch of them. Because the panel is in the public right-of-way, the permit is filed before the saw starts and the inspector is booked.
Scott Ferreira stands on the end of every panel, marks the ones that move, checks the drive crossing and writes the figure at the curb.
You approve the panels and the date, and the encroachment permit is filed with the City's review time built into the start. Nothing is cut yet.
The panel is sawn on its score lines and lifted out, the wet fines dug out until the plate stops sinking, and the neighbors drilled for dowels.
Crushed rock compacted, forms set to the walk either side, the inspector's look, then a morning pour, edged, tooled at the old spacing and broomed.
The panel is kept damp and barricaded for 48 hours, cars stay off an approach for 7 days, and the walk-through and the written guarantee follow.
Behind the number
The count of panels starts the figure and the ground under them finishes it. Two frontages with the same three lips can be a day apart in work once the first panel is out and the base is seen. Every estimate is measured and written on site.
A 1960s house south of Adams with one or two panels rocking at the drive is the base case, and the ground under them decides the digging.
A corner carries twice the walk, the curb ramp at the crossing, and barricades on two streets instead of one, so it is measured as two frontages.
Below the mesa the base comes out deeper and goes back as more rock, and where water stands in the cut the pour waits for it to drain away first.
Panels a car crosses are poured 6 inches on mesh and tied to the approach, and if the approach is redone with them it is measured as its own area.
The visit and the written figure are free, and the call back to book it comes within 1 business day. Bring the City's notice if you have one. (657) 312-3698 or send us a message.
Send the form or call, and someone rings back within 1 business day to fix a time. Scott Ferreira stands on every panel, marks the ones that move and writes the figure at the curb, so you know which the City will want done.
Walks we rebuilt
Three reviews left on Google, Facebook and the BBB, each about a sidewalk rather than a driveway or a patio, and each about a walk that had been moving before it was rebuilt.
“The City painted two panels in front of our house near Central Park and one tipped every time the mail carrier stepped on it. They dug out mud where the base should have been, put rock in, doweled the new panels to the old and had the barricades down in two days. Winter has not moved them.”
“Our driveway crosses the walk and the panels had broken into pieces under the trucks that deliver to us. They pulled the encroachment permit, poured those four panels 6 inches with mesh and matched the score lines so you cannot see the join. Trucks have been over it for a year now.”
“Three panels on our corner off Springdale had dropped at the joints and one lip was over an inch. Scott Ferreira came out, stood on each one, and told us which two could wait. They rebuilt three on a rock base and doweled them, and it took a day and a half. Level as the day it was poured.”
Before you book
Whose walk it is, what the City permits, what the estimate covers and how long the street is closed, answered for a tract frontage on the wet side of Huntington Beach.
The base, more than the number of panels. A panel lifted out over dry sand is dug a few inches and poured; one over wet fines on the lowland side is dug until the plate stops sinking and the hole filled with rock, which can double the work under a slab of the same size. Panels a car crosses are 6 inches rather than 4. Each panel is measured and written at the curb, with the depth beside it.
Two to three days for a frontage of a few panels. Sawing, lifting out and digging the base is the first day, rock, forms and the inspector's look are the next morning with the pour behind them, and the barricades stay up 48 hours after that. A driveway crossing keeps the cars on the street for 7 days. Neighbors get a way around the work the whole time, which the permit requires.
Yes. The encroachment permit from Public Works, its fee, the barricades and the inspector's visits are written into the figure, and so is hauling the old panels away. What sits outside it is named at the visit rather than added later, a water meter box that has to be reset, a tree root that has to be cut with the City's say-so, or a curb that breaks when the panel comes out.
In California the owner of the property the walk fronts is responsible for keeping it up, under the Streets and Highways Code, and the City can require the repair of a lip it has marked. The walk still sits in the public right-of-way, so replacing it needs an encroachment permit from Public Works whoever pays for it. Ask the City first whether it has a program for your street, and we work either way.
No, as a rule. A panel that has dropped or rocked over years is wear to a carrier, not a sudden loss, and a City notice does not change that. The exception is damage from a covered event, a burst main washing the base out or a vehicle mounting the curb, and a lip that injured someone is a liability claim, which is the reason the City marks them. Photograph the walk before it is cut, and ask your carrier.
How it was built, meaning the base dug out and replaced with rock, the compaction, the thickness, the dowels and the finish, with those terms printed on the estimate before you sign. It is a written workmanship guarantee against defects in how it was built. A neighboring panel we did not rebuild dropping beside the new one sits outside it, as does a root from a parkway tree. Where the fault is ours we fix it.
A 3,500 psi ready-mix over clean crushed rock rather than a sandy base that holds water, with welded mesh in any panel a car crosses and smooth steel dowels drilled into the panels either side. The surface is broomed across the line of travel and tooled at the old score spacing, so it matches the walk on both sides. The mix and the base depth are named on the estimate, panel by panel.
No, because the work is at the curb and needs nothing from inside the house except water from a hose bib. You are needed for the walk of the frontage at the start and the walk-through at the end. In between, keep the cars off a driveway crossing until the barricades come down, and tell us if a delivery is due, since a truck over a fresh panel is the one thing that undoes it.
Towns we pour in
The eight nearest towns to the office on Edinger Avenue, with the distance to each. Each one permits work on its own walks at its own counter, and we file with whichever it is before a panel is cut.
Four jobs that share a permit, a base detail or a day on site with a new walk, poured by the same crew and itemized on the one written estimate.
The approach a walk crosses, redone on the same encroachment permit and the same morning.
The step from the walk up to a raised frontage, poured with the panel so the two cannot part.
The saw cut on the score line that takes one panel out and leaves its neighbors whole.
A low wall holding a front yard off the walk where the lot sits above the street.
Call or send the form and you hear back within 1 business day. Say how many panels the City has marked, whether a driveway crosses them, and which side of Adams Avenue you are on, and the visit is booked for a day inside the week.
